| Modo de trabalho: | montagem a frio, lado único, lado duplo | Modo de aquecimento: | Rolo de aço |
|---|---|---|---|
| Diâmetro do rolo: | 79 mm | Temperatura de revestimento: | 70 ~ 110 ℃ |
| Espessura do filme: | 80 ~ 350g | Diâmetro do núcleo da membrana: | 1 pol./3 pol. |
| Tempo de aquecimento: | 5 a 10 minutos | Velocidade de cobertura do filme: | 1 ~ 3m/min |
| Largura máxima do filme: | 340 milímetros | Modo de exibição: | Visor digital |
|
Work Mode
|
cold mounting , single side , double side
|
|
Heating Mode
|
steell roll
|
|
Roll Diameter
|
79 mm
|
|
Coating Temperature
|
70 ~ 110 ℃
|
|
Film Thickness
|
80 ~ 350 g
|
|
Membrane Core Diameter
|
1in / 3in
|
|
Heating Time
|
5 ~ 10 min
|
|
Film Covering Speed
|
1 ~ 3 m/min(1 ~ 9 speed opition)
|
|
Max. Film Width
|
340 mm
|
|
Display Mode
|
digital display
|
|
Control Mode
|
key temperature control
|
|
Pressurization Mode
|
pull the pressurized spring
|
|
Paper Feed Mode
|
manual
|
|
Automatic Paper Collection Function
|
automatic winding structure
|
|
Automatic Tension Function
|
no
|
|
Dashed Line Function
|
perforating knife
|
|
Crimp Prevention Function
|
gravity stretch anti-crimp design
|
|
Trimming Function
|
automatic trimming
|
|
Electric Current
|
5.5 A
|
|
Voltage
|
220V
|
|
HZ
|
50 Hz
|
|
Humidity
|
20% ~ 70%
|
|
Net Weight
|
42 kg
|
|
Gross Weight
|
48 kg
|
|
Packing Dimension
|
670 * 640 * 410 mm
|
